Overview:
PG-M600 series OTDR is a In line with the international standards of test data with perfect simulation software, so that your report is more simple., which integrates auto OTDR, expert OTDR, event map, optical power meter, visual fault location, power adjustable stable light source, end face detection, optical loss test, cable line length / sequence test, cable tracking and other functions. It has full-view capacitive touch-screen supports multi-touch . It is the right assistant for optical cable construction, installation and maintenance, project acceptance and on-site repair.
Features:
1. 9-in-1 functions
2. The 4.3-inch full-view capacitive touch-screen supports multi-touch
3. Cover plate type tempered glass panel, don't worry about screen scratch.
4. Support horizontal version, vertical version, perfect fusion of the two habits of user operations.
5. Support charging treasure charging, do not worry about the battery is not enough.
6. In line with the international standards of test data with perfect simulation software, so that your report is more simple.
7. Sink type light port design, so that the instrument light port can get better protection.
8. Support pen-driver, SD card and Micro USB export data protection.
9. Any interface supports screen capture
Item |
Value |
||
Place of Origin |
Guangdong,China |
||
Brand Name |
piogoods |
||
Model Number |
PGM600 |
||
Type |
Testers &Tools |
||
No. of Fiber |
1 |
||
Use |
ftth |
||
Product name |
mini fiber optic tester OTDR |
||
Wavelength |
1310nm/1550nm |
||
Dynamic range |
26dB/24dB |
||
Test distance |
64km |
||
Function |
OTDR+OPM+VFL+laser source+iOLM |
||
Weight |
2kg |
||
Warranty |
1 Year |
||
Color |
Blue |
||
Packing |
1pc/box |
||
Certification |
RoHS |
