1. Dynamic range up to 50dB.
2. Short zone: EDZ 0.8m, ADZ 4.5m
3. Auto/Manual test and analysis
4. Multi-wavelength testing
5.Visible laser source function.
6. In-Line test and through Splitter test(1625/1650nm with filter)
7. OTDR Module up to four wavelength/loss/return loss measurement, connector/splice/macro bend/fiber-end detection
8. LAN/WAN/FTTx application
9. SOR and JPG file format
10. flexible file naming
Specifications:
Display | 7 inch TFT Touch Screen(800x480) | ||
Connectivity |
USBx2;10/100M Mbits/s RJ-45x1 | ||
Memory |
2GB | ||
Power supply | Rechargeable Li-lon Battery/AC adapter |
||
Working Temp | -20℃-50℃ |
||
Storage Temp | -40℃-60℃ |
||
Humidity | 0-95%(Non-Condensing) |
||
Weight | 2.1kg |
||
Dimensions(LxWxH) |
290x175x75mm |
Wavelength(±20nm) |
